This interactive is designed to help students understand the statistical approach underpinning the drawing of a best-fit line for practical work. For context, our national exams have a practical component where students will need to plot their data, often following a linear trend, on graph paper and to draw a best-fit line to determine the gradient and y-intercept.

The instructions to students on how to draw the best-fit line is often procedural without helping students understand the principles behind it. For instance, students are often told to minimise and balance the separation of plots from the best-fit line. However, if there are one or two points that are further from the rest from the best-fit line (but not quite anomalous points that need to be disregarded), students would often neglect that point in an attempt to bring the best fit line as close to the remaining points as possible. This results in a drastic increase in the variance as the differences are squared in order to calculate the "the smallest sum of squares of errors".

This applet allows students to visualise the changes in the squares, along with the numerical representation of the sum of squares in order to practise "drawing" the best-fit line using a pair of movable dots. A check on how well they have "drawn" the line can be through a comparison with the actual one.

Students can also rearrange the 6 data points to fit any distribution that they have seen before, or teachers can copy and modify the applet in order to provide multiple examples of distribution of points.

Did this simple interactive upon request by a colleague who is teaching the JC1 topic of Oscillations.

Based on the following question, this is used as a quick visual to demonstrate why there must be a minimum depth before the boat approaches harbour.

The rise and fall of water in a harbour is simple harmonic. The depth varies between 1.0 m at low tide and 3.0 m at high tide. The time between successive low tides is 12 hours. A boat, which requires a minimum depth of water of 1.5 m, approaches the harbour at low tide. How long will the boat have to wait before entering?

The equation of the depth of water H based on the amplitude of the tide a can be given by $H = H_o + a \cos \omega t$ where $H_o$ is the average depth of the water.

$H = H_o + a \cos \omega t$

When H = 1.5m,

$1.5 = 2.0 - 1.0 \cos (\dfrac{2 \pi}{12}t)$

$\cos (\dfrac{2 \pi}{12}t) = 0.5$

$t = 2.0 h$

Team-based learning is a pedagogical approach that facilitates learning through individual testing and group collaboration. Students are first given time to work on answers individually using the Individual Readiness Assurance Test (iRAT). They then work in teams to discuss the same problems in order to arrive at a consensus and check their answers against a pre-filled MCQ scratch card that reveals if their selected answer is correct or wrong, after which an immediate feedback is given. This is known as the Team Readiness Assurance Test (tRAT). If they got the answer wrong, teams get a chance to either appeal their answer or to try the same question again. A clarification session then ensues, with teachers focusing more on questions that teams have difficulty in.

Schools that want to use Team-Based Learning might either subscribe to platforms that allow for repeated attempts such as InteDashboard or purchase the Immediate Feedback Assessment Technique (IF-AT) scratch cards. There are some free options such as that from Cosma Gottardi.

However, I was wondering if a simple one could be done with Google Form, using the quiz mode together with branching options, to achieve the same results. I tested it out immediately last night and came up with this proof-of-concept. It seems possible and easy to edit.

I created a template for anyone who is keen to try:

https://docs.google.com/forms/d/1l2msnjt2ioSWcmz4GpQWgm1_CoFBRQDmBOwZQopnefI/edit?usp=sharing

I designed this 3D teaching tool using Tinkercad and printed it out so that my colleague can use it to demonstrate the effect of a centrifuge.

As the toy is being spun, the ball bearings will appear to be thrown outwards. The centripetal forces that are meant to keep them in circular motion is made up of friction and any contact force due to the curvature of the base. If the rate of spin is sufficiently high, there will be insufficient contact force keeping the ball bearings in a circular path and hence, they will spiral outward and land into the cups found near the ends when the spinning stops.

Anyone can 3D-print this design as it had been uploaded into Thingiverse. This is my first original submission and can be found here. You will need 4 tiny balls of no more than 8 mm in diameter. The top is to be covered with a clear sheet of plastic cut-out after tracing the shape using a marker. The sheet can be stuck on the top using normal glue. This plastic cover serves to ensure the balls do not fly out if spun too fast.

These are my 3D-printed Meissner tetrahedrons, each maintaining the same height when rolled in any direction. The Meissner tetrahedron is a 3D version of the 2D Reuleaux triangle, which is a triangle with constant width. A flat platform can be placed on top and remain level when pushed around. The STL files can be obtained from Thingiverse. Sliced using Cura (with treelike supports) and printed with my Creality Ender 3.

Not exactly a physics teaching aid, but it demonstrates the affordance of 3D printing, which allows us to produce interesting objects overnight for lessons or if inspiration strikes. I am going to print a Gomboc next, which is an object when resting on a flat surface have just one stable and one unstable point of equilibrium, and is relevant to the topic of turning effects of forces.
